Truck Mounted Drill Rigs

Exploration

The Comacchio CX line of exploration drilling rigs includes four truck-mounted rigs that range from lightweight compact units installable on small 4x4 trucks, up to 30-tonnes-pull rigs mounted on heavy-duty 8x8 trucks.

The main advantage of this truck mounted version lies in the flexibility and mobility, allowing for fast rig-up, rig-down and re-deployment. These robust and reliable units are designed and built to tackle vast drilling campaigns, operating in remote areas and harsh environmental conditions.

Like all machines of the Comacchio CX line, our truck-mounted rigs can be used for both diamond core drilling with wireline systems and for reverse circulation drilling with down- the-hole hammer and dual wall pipes (RC drilling). This ability to perform multiple drilling techniques from the same rig is based on the use of advanced modular hydraulic circuits that allow for the installation of a wide range of rotary heads and application-specific accessories. In order to comply with the stringent safety regulation of the mining industry, Comacchio CXT drilling rigs can be equipped with hands-free automated and semi-automated tool handling systems that reduce manual handling of the equipment.

Truck Mounted Drill Rigs MODELS

CX-T 10

CX-T 10

CX-T 10

EU | US

Engine Power 115 - 119 kW
Retract Force 9.500 daN
Weight  8.000 - 8.500 kg

Engine Power 154 - 160 HP
Retract Force  21,360 lbs
Weight 17,650 - 18,750 lbs

Continue

CX-T 15

CX-T 15

CX-T 15

EU | US

Engine Power 126 - 160 kW
Retract Force 15.000 daN
Weight 7.500 - 10.000 kg

Engine Power 169 - 215 HP
Retract Force 33,720 lbs
Weight 16,550 - 22,100 lbs

Continue

CX-T 20

CX-T 20

CX-T 20

EU | US

Engine Power 205 - 245 kW
Retract Force 20.000 daN
Weight 12.000 - 18.000 kg

Engine Power 278 - 333 HP
Retract Force 44,962 lbs
Weight 26,400 - 39,700 lbs

Continue

CX-T 30

CX-T 30

CX-T 30

EU | US

Engine Power 205 - 245 kW
Retract Force 30.000 daN
Weight 16.000 - 19.000 kg

Engine Power 278 - 333 HP
Retract Force 67,443 lbs
Weight 35,300 - 41,900 lbs
