CA 3030

High Performance

The CA 3030 is designed for water well applications. The rig can provide up to 30,000 daN pull and support all single head rotary and rotary-percussive drilling methods. In particular, the CA 3030 can be set up both for direct rotary drilling with water/mud flushing and for reverse circulation drilling, passing from one set up to the other with minimal variations on the rotary head. The versatility of the CA 3030 is also given by the large number of accessories available, such as clamps, winches, pumps and compressors.


Engine Power 245 kW (333 HP)
Max Width 2.400 mm 7.9 ft
Weight 28.000 kg 61,700 lbs
Mast Feed 7.000 mm 23 ft
Feed Force 12.000 daN 26,977 lbs
Retract Force 30.000 daN 67,442 lbs
Rotary Torque 3.100 daNm 22,864 lb*ft
Rotary Speed Range 140 rpm
Clamp Range 90 - 520 mm 3.5 - 20.5 in
