TECH DATA

Engine Power 55 kW (74 HP)
Max Width 1.925 mm 6.3 ft
Weight 7.000 - 8.500 kg 15,400 - 18,700 lbs
Mast Feed 3.500 mm 11.5 ft
Feed Force 4.500 daN 10,116 lbs
Retract Force 6.500 daN 14,612 lbs
Rotary Torque 450 - 1.400 daNm 3,319 - 10,330 lb*ft
Rotary Speed Range 55 - 380 rpm
Clamp Range 45 - 260 mm 1.8 - 10.2 in
