Heavy Duty Versatility
Based on the concept of the MC 15, the MC 15 P offers higher performance thanks to the superior motorization capable of delivering up to 168 kW (225 HP) of power. The MC 15 P is a "multipurpose" machine that can carry out any type of foundation and soil consolidation drilling project, from micro-piles to jet grouting, as well as anchors and soil nailing. A distinctive feature of the MC 15 P is the variety of movements and inclination angles of the mast that this rig can reach. The machine can mount a wide selection of rotary heads, hydraulic hammers, water and mud pumps, winches and loaders for drilling rods. The fully flexible design lends itself to a wide range of drilling processes using rotary and rotary/percussion techniques. The increased performance of the engine makes it particularly suitable for the use of drilling techniques with double-head systems.
Engine Power | 168 kW (225 HP) | |
Max Width | 2.300 mm | 7.5 ft |
Weight | 16.500 - 18.500 kg | 36,400 - 40,700 lbs |
Mast Feed | 3.550 - 7.000 mm | 11.6 - 22.9 ft |
Feed Force | 8.000 daN | 17,984 lbs |
Retract Force | 8.000 daN | 17,984 lbs |
Rotary Torque | 1.000 - 3.100 daNm | 7,375 - 22,864 lb*ft |
Rotary Speed Range | 48 - 260 rpm | |
Clamp Range | 45- 530 mm | 1.8 - 20.9 in |
