TECH DATA

Engine Power 55 - 74 kW (74 - 99 HP)
Max Width 1.600 - 1.700 mm 5.3 - 5.6 ft
Weight 7.000 - 8.000 kg 12,800 - 17,600 lbs
Mast Feed 3.500 mm 11.5 ft
Feed Force 4.500 daN 10,116 lbs
Retract Force 6.500 daN 14,612 lbs
Rotary Torque 450 - 1.400 daNm 3,319 - 10,325 lb*ft
Rotary Speed Range 55 - 980 rpm
Clamp Range 45 - 325 mm 1.8 - 12.8 in
