TECH DATA

Engine Power 86 - 100 kW (115 - 134 HP)
Max Width 1.600 - 2.300 mm 5.2 - 7.6 ft
Weight 8.000 - 9.500 kg 17,600 - 21,000 lbs
Mast Feed 3.500 mm 11.5 ft
Feed Force 4.500 daN 10,116 lbs
Retract Force 6.500 daN 14,612 lbs
Rotary Torque 450 - 1.550 daNm 3,319 - 11,432 lb*ft
Rotary Speed Range 70 - 980 rpm
Clamp Range 45 - 325 mm 1.8 - 12.8 in
