| Diesel engine | Yanmar 4TNV98C-T (EU Stage Stage V - US EPA Tier 4f) | |
| Power rating | 54 kW | 73 HP |
| Nominal max torque | 44 kNm | 32,450 lbf*ft |
| Weight | 13000 kg | 28,660 lbs |
| CFA | ||
| Max pile diameter | 750 mm | 2' 6" |
| Max length of augers | 8.5 m | 27' 11" |
| Max length of auger extension | 4 m | 13' 1" |
| Max pile depth | 8.1 + 4 = 12.1 m | 26’ 7” + 13‘ 1" = 39’ 8” |
| Extraction force | 170 kN | 37,217 lbs |
| Crowd force on auger (optional) | 60 kN | 13,500 lbs |
