TECH DATA

Diesel engine Cummins QSB6.7  (EU Stage IIIA/Stage V - US EPA Tier 3 / Tier 4f)
Power rating 201 - 209 kW/ 2000 rpm 274 - 284 HP/2000 rpm
Nominal max torque 190 kNm 140,000 lbf*ft
Weight 43700 kg 96,350 lbs

CFA (T4 XXL)
Max pile diameter 1000 mm 3' 3"
Max length of augers 19.5 m 63' 11"
Max length of auger extension 6 m 19' 8"
Max pile depth 19 + 6 = 25 m 62’ 4” + 19‘ 8" = 82’
Extraction force 480 kN 107,900 lbs
Crowd force on auger (option) 100 kN 22,500 lbs
