| Diesel engine | Cummins QSB6.7 (EU Stage IIIA/Stage V - US EPA Tier 3 / Tier 4f) | |
| Power rating | 201 - 209 kW/ 2000 rpm | 274 - 284 HP/2000 rpm |
| Nominal max torque | 190 kNm | 140,000 lbf*ft |
| Weight | 42500 kg | 93,700 lbs |
| CFA (T4) | ||
| Max pile diameter | 1000 mm | 3' 3" |
| Max length of augers | 17 m | 55' 9" |
| Max length of auger extension | 6 m | 19' 8" |
| Max pile depth | 16.5 + 6 = 22.5 m | 54’ 2” + 19‘ 8" = 73’ 10” |
| Extraction force | 480 kN | 107,900 lbs |
| Crowd force on auger (option) | 100 kN | 22,500 lbs |
