| Diesel engine | Cummins QSB4.5 (EU Stage III/US EPA Tier 3) - B4.5 (Stage V/Tier 4f) | |
| Power rating | 123 - 142 kW/ 2000 rpm | 165 - 190 HP/2000 rpm |
| Nominal max torque | 132 kNm | 97,300 lbf*ft |
| Weight | 29550 kg | 65,150 lbs |
| CFA (T4) | ||
| Max pile diameter | 800 mm | 2' 7" |
| Max length of augers | 13.5 m | 44' 4" |
| Max length of auger extension | 6 m | 19' 8" |
| Max pile depth | 13 + 6 = 19 m | 42’ 8” + 19‘ 8" = 62’ 4” |
| Extraction force | 320 kN | 71,900 lbs |
| Crowd force on auger (optional) | 45 kN | 10,100 lbs |
