| Diesel engine | Cummins QSB6.7 (EU Stage IIIA/Stage V - US EPA Tier 3 / Tier 4f) | |
| Power rating | 201 - 209 kW/ 2000 rpm | 274 - 284HP/2000 rpm |
| Nominal max torque | 190 kNm | 140,000 lbf*ft |
| Weight | 41500 kg | 91,500 lbs |
| CFA/WPD (Quick Conversion CFA) | ||
| Max pile diameter | 1000 mm | 3' 3" |
| Max length of augers | 16 m | 52' 6" |
| Max length of auger extension | 7 m | 23' |
| Max pile depth | 14 + 7 = 21 m | 46' + 23‘ = 69' |
| Extraction force | 330 kN | 74,200 lbs |
| Crowd force on auger | 140 kN | 31,470 lbs |
